Acrel WHD20R-22 intelligent smart digital Temperature and Humidity Controller

Name: Acrel WHD20R22 intelligent smart digital Temperature and Humidity Controller
Brand: Acrel
Price: 50.00 USD

Wholesale Acrel WHD20R-22 intelligent smart digital Temperature and Humidity Controller from china suppliers

Certification : CE

Place of Origin : Jiangsu, China

Brand Name : Acrel

Model Number : WHD20R-22

MOQ : 1-19 Pieces

Price : $50.00

Warranty : 2 years

Customized support : ODM

Display : LED Display

Communication : RS485 Port MODBUS-RTU Protocol

Installation : 35mm Din Rail

Function : Measurement

Temperature range : -40.0℃~99.9℃

Humidity range : 20%RH~90%RH

Certificate : CE ISO9001

Contact capacity : 5A/AC250V

Power supply : AC 85~265V DC 100~350V

Brand : OEM ODM

Selling Units : Single item

Single package size : 17X15X13 cm

Single gross weight : 0.400 kg

Package Type : It is packed in a crash bag and then put into a cardboard box.

Contact Now

Acrel WHD20R-22 intelligent smart digital Temperature and Humidity Controller

WHD20R-22 Temperature & Humidity Controller

● Optional functions: alarm, communication

● Temperature and humidity measuring & controlling

● DIN rail mounted

Products Description

Characteristic

Function

Accuracy
Temperature ±1℃
Humidity ±5%RH

Auxiliary power supply
AC 85-265V, DC 100-350V

Consumption
Auxiliary power supply:
Basic power consumption(≤0.8w)
Relay power consumption(each channel≤0.7w)

Installation:
DIN rail 35mm

Dimension(L*W*H):
88*90*52mm

Appearance

Wiring

Technical Parameter			Value
Measuring range	Temperature	-40.0℃～99.9℃
Measuring range		Humidity	20%RH～90%RH
Accuracy	Temperature	±1℃
Accuracy		Humidity	±5%RH
Analog output			DC 4～20mA
Set range of controlling parameter	Heating for Temperature rising	-40.0℃～40.0℃
		Blowing for temperature decreasing	0℃～99.9℃
		Humidity control	20%RH～90%RH
Contact capacity			5A/AC250V
Communication			RS485(MODBUS-RTU)
Auxiliary power supply	Working range	AC 85～265V DC 100～350V
Auxiliary power supply		Consumption	Basic power consumption(≤0.8w)+ relay power consumption(each channel≤0.7w)
Insulation resistance			≥100MΩ
Environment	Temperature	-20℃～+60℃
		Humidity	≤95%RH(No condensation)
		Altitude	≤2500 m

Technical Parameter			Value
Measuring range	Temperature	-40.0℃～99.9℃
Measuring range		Humidity	20%RH～90%RH
Accuracy	Temperature	±1℃
Accuracy		Humidity	±5%RH
Analog output			DC 4～20mA
Set range of controlling parameter	Heating for Temperature rising	-40.0℃～40.0℃
		Blowing for temperature decreasing	0℃～99.9℃
		Humidity control	20%RH～90%RH
Contact capacity			5A/AC250V
Communication			RS485(MODBUS-RTU)
Auxiliary power supply	Working range	AC 85～265V DC 100～350V
Auxiliary power supply		Consumption	Basic power consumption(≤0.8w)+ relay power consumption(each channel≤0.7w)
Insulation resistance			≥100MΩ
Environment	Temperature	-20℃～+60℃
		Humidity	≤95%RH(No condensation)
		Altitude	≤2500 m

Technical Parameter			Value
Measuring range	Temperature	-40.0℃～99.9℃
Measuring range		Humidity	20%RH～90%RH
Accuracy	Temperature	±1℃
Accuracy		Humidity	±5%RH
Analog output			DC 4～20mA
Set range of controlling parameter	Heating for Temperature rising	-40.0℃～40.0℃
		Blowing for temperature decreasing	0℃～99.9℃
		Humidity control	20%RH～90%RH
Contact capacity			5A/AC250V
Communication			RS485(MODBUS-RTU)
Auxiliary power supply	Working range	AC 85～265V DC 100～350V
Auxiliary power supply		Consumption	Basic power consumption(≤0.8w)+ relay power consumption(each channel≤0.7w)
Insulation resistance			≥100MΩ
Environment	Temperature	-20℃～+60℃
		Humidity	≤95%RH(No condensation)
		Altitude	≤2500 m

Technical Parameter			Value
Measuring range	Temperature	-40.0℃～99.9℃
Measuring range		Humidity	20%RH～90%RH
Accuracy	Temperature	±1℃
Accuracy		Humidity	±5%RH
Analog output			DC 4～20mA
Set range of controlling parameter	Heating for Temperature rising	-40.0℃～40.0℃
		Blowing for temperature decreasing	0℃～99.9℃
		Humidity control	20%RH～90%RH
Contact capacity			5A/AC250V
Communication			RS485(MODBUS-RTU)
Auxiliary power supply	Working range	AC 85～265V DC 100～350V
Auxiliary power supply		Consumption	Basic power consumption(≤0.8w)+ relay power consumption(each channel≤0.7w)
Insulation resistance			≥100MΩ
Environment	Temperature	-20℃～+60℃
		Humidity	≤95%RH(No condensation)
		Altitude	≤2500 m
